Description

An indoor unit for every scenario.

Carrier provides a variety of quiet and aesthetic indoor units. With 4 types of cassettes, 3 types of ducts, 5 types of console and high wall, and 1 type of ventilation units, you are sure to find the right indoor unit for you.


High Wall 40VK*S-7S(2)

Type: High Wall
Motor type: DC
Capacity: 1.5 – 9 kW
Stylish & exclusive design with LED display
Cover panel using ABS-material to improve surface brightness and tenacity
Easy-support clip to enable simple installation
High efficiency DC powered fan
PCB integrated design, flexible piping direction arrangement
PM 2.5 filter available (optional)
Easy service and maintenance
Easy removal of air filters for cleaning
Remote on/off function and alarm function
Easy access to indoor unit components
Comfortable
Washable filter included
Independent control of the air flow directions
Multi-gear air speed selection
Aesthetic
Streamlined design
Easily fits in with different interior designs


Round-Way Cassette 40VU*R-7E

Type: Cassette
Motor type: DC
Capacity: 2.2 – 16 kW
Round corner design
Unique round-way air outlet and air distribution to reduce blind spots
DC powered fan with low sound level and high efficiency
Built-in drain pump
Innovative four-way independent airflow control, 6 adjustable louver positions and 1296 airflow combinations
Up to 4.2m ceiling height with a large capacity
Automatic display of fault codes
Smart Self Diagnostic Function
By adding digital tube displayer on the display board, the error codes can be displayed directly for trouble shooting
Easy service and maintenance
Easy removal of air filters for cleaning
Remote on/off function and alarm function
Easy access to indoor unit components
Save energy
Optional panel with presence sensor
Comfortable
Washable filter included
Multi-gear air speed selection
Independent control of air flow directions
Aesthetic
Streamlined design
Easily fits with different interior designs
Ultra-thin and compact design
Save ceiling space
Convenient
Reserved fresh air inlet
Built-in drain pump
Easy disassembly of maintenance panel


Compact 4-Way Cassette 40VU*C-7S

Type: Cassette
Motor type: DC
Capacity: 1.5 – 5.6 kW
Compact design: installation restrictions reduced to enable high flexibility
ldeal for standard ceiling tiles and small rooms: 570*570 mm body size and 620*620 mm panel size
Built-in drain pump
lndependent control of four-way air flow
Low sound level, high-efficiency and comfort
Knockout hole for outside air
Compact DesignCompact Design
Extremely compact casing (570 mm in width and 260 mm in depth)
All models can be installed without a hoist
Easy service and maintenance
Easy removal of air filters for cleaning
Easy access to indoor unit components
Built-in drain pump
Convenient
Reserved fresh air inlet
Comfortable
Washable filter included
Multi-gear air speed selectionMulti-gear air speed selection


2-Way Cassette 40VU*2-7G

Type: Cassette
Motor type: AC
Capacity: 2.2 – 5.6 kW
Compact design: only 220mm in height
Built-in drain pump
Unique ceiling anti-fouling design
Dual air supply to distribute air in two directions with quiet operation
Stylish design & slim body
220 mm height
Built-in drain pump
Flat-type suction grille design makes maintenance work very easy
Convenient
Easy disassembly of maintenance panel
Comfortable
Washable filter included
Multi-gear air speed selection


1-Way Cassette 40VU*1-7E

Type: Cassette
Motor type: DC
Capacity: 1.5-3.6 kW
DC powered fan with industry-leading noise levels down to 25dB(A)
Return air panel serves as a service port to maintain the unit
Built-in drain pump
Unique ceiling anti-fouling design
Easy service and maintenance
Easy removal of air filters for cleaning
Easy access to indoor unit components
Built-in drain pump
Makes the installation free from limitation of story height
Height 185mm only
Compact design
Convenient
Easy disassembly of maintenance panel
Comfortable
Washable filter included
Multi-gear air speed selection


Slim Duct 40VD*L-7E

Type: Duct
Motor type: DC
Capacity: 1.5 – 7.1 kW
Ultra-thin design: 185 mm height to accommodate in limited space
DC motor with 6 fan speeds to provide unique and comfort control
Built-in drain pump
Bottom or rear air return
Static pressure setting 0/30 Pa
Can be installed with or without discharge and return plenum
Slim, Light Weight & Compact Design
185mm height
Easy installation
Available optional outlet and inlet panels
Built-in drain pump
With 600 mm pump head
Comfortable
Washable filter included
Multi-gear air speed selection
Convenient
Optional location of air return
Friendly installation
Adjustable static pressure
Flexible selection according to the actual installation


Standard Static Duct 20-200 Pa 40VD*S-7S

Type: Duct
Motor type: DC
Capacity: 1.5 -16 kW
Elegant slim design with T-shaped lifting eye with adjustable width and length direction
Hidden installation for a clean and sophisticated appearance
Standard draining pump with maximum 1200 mm lift
Better sealing pipe liner made of heat retaining EPS material
Slim and compact design
248 mm in height
Built-in drain pump
Flexible bottom or rear air return
Comfortable
Washable filter included
Multi-gear air speed selection
Optional location of air return
Friendly installation
Adjustable static pressure
Flexible selection according to the actual installation
Reserved fresh air inlet


High Static Duct 0 – 250 Pa 40VD*H-7S

Type: Duct
Motor type: DC
Capacity: 2.2 – 28 kW
Compact 280 mm height
6.35 mm coil copper pipe to ensure more precise & efficient refrigerant distribution
Top-performing composite material fan wheel blower with light air resistance
ESP can be changed according to requirements to minimise the noise
Installer-friendly buckle design of electric box & pull-out fan motor design
Built in drain-pump
Slim, light weight and compact design
Uniform 280 mm in height
Built-in drain pump with 600 mm pump head
Energy saving
6:35mm heat exchange tube ensures more precise refrigerant distribution and higher efficiency
High performance composite material wind wheel, light and small air resistance
Comfortable
Washable filter included
Multi-gear air speed selection
Aesthetic
Ultra thin and compact design
Convenient
Adjustable static pressure
Flexible selection according to the actual installation
Drain pump


Flex Ceiling/Floor with DC fan 40VC*F-7S

Type: Ceiling floor
Motor type: DC
Capacity: 2.8 – 16 kW
Ultra-compact design (230 mm), elegant balance of flexibility and simplicity
Appealing, even without screen cover
Easy installation and maintenance
Easy access to PCB
Simultaneous left and right swing control for optional freestyle airflow
PM 2.5 filter (optional)
Easy service and maintenance
Easy removal of air filters for cleaning
Remote on/off function and alarm function
Easy access to indoor unit components
Aesthetics
Ultra thin body features wave-shaped vents on both sides
Visually screw-free, yet easy to maintain
Multiple air distribution directions
Comfortable
Washable filter included
Independent control of the airflow directions
Multi-gear air speed selection
Convenient
Easy disassembly of the maintenance panel


Flex Ceiling/Floor with AC fan 40VC*F-7G

Type: Ceiling floor
Motor type: AC
Capacity: 2.8 – 7.1 kW
Flexible installation, on the floor or under the ceiling
Slim design- 199mm
Multiple direction for connection pipe setting
Comfortable
Washable filter included
Independent control of the air flow direction
Multi-gear air speed selection
Aesthetic
Streamlined design
Easily fits in with different interior designs
Convenient
Easy disassembly of the maintenance panel


2-Way Console 40VL*B-7E

Type: Floor standing units
Motor type: DC
Capacity: 1.5 – 5 kW
Compact design makes installation flexible and easy on the floor or against the wall
Five speed airflow and two-way airflow mode that automatically adjusts for extra comfort and flexibility
Automatic adjusting to carpet airflow when switched to two-way airflow mode
Stylish & elegant design
Easy installation
The indoor units can be installed on the floor or on the wall. Its flexibility allows for easy installation.
Compact unit, space saving
The console indoor unit is very slim and will be harmonious with any room. It can be placed at the corner, and is very space saving.
Comfortable
Washable filter included
Multi-gear air speed selection
Aesthetic
Streamlined design
Easily fits in with different interior designs
Convenient
Easy disassembly of the maintenance panel


Console Recessed 40VL*R-7G

Type: Floor standing units
Motor type: AC
Capacity: 2.2 – 3.6 kW
Compact design suitable for installation space as little as 221 mm
Good solution for installation beneath a window
Washable filter fitted as standard
30 Pa available static pressure for small ducting or higher efficiency filter
Comfortable
Washable filter included
Multi-gear air speed selection


HRV 40VH*A-7G

Type: Ventilation
Motor type: AC
Capacity: 3.5 – 14 kW
Efficiency up to 78% on temperature exchanger & 65% on enthalpy (cooling)
Independent 220V power supply
Can run in slight over-pressure or under-pressure mode
Efficient heat recovery air processing
Comfortable
Washable filter included
Multi-gear air speed selection
